🏠 Modern 20×40 House Plan Design with Drawing Room

Plot Size: 20 feet (Front) × 40 feet (Depth)
Built-up Area: Approx. 800 sq.ft
Style: Single-floor 1BHK with dedicated drawing and living spaces

🔻 Room-by-Room Dimensions and Details:

1. Veranda / Entry Porch

   📏 Size: 9′-3″ × 5′-6″
   ➤ Compact open space for entry or sit-out. Enhances curb appeal and provides a welcoming area at the main door.

2. Drawing Room

   📏 Size: 9′-3″ × 10′-6″
   ➤ A semi-private room ideal for formal meetings or guest seating, located right after the veranda.

3. Living Hall

   📏 Size: 9′-3″ × 16′-6″
   ➤ Large and elongated space ideal for family entertainment, TV setup, and everyday lounging. Centrally placed for easy access.

4. Bedroom

   📏 Size: 9′-3″ × 10′-6″
   ➤ Comfortable bedroom space with proper room for double bed, wardrobes, and side table. Ensures privacy being at the back of the layout.

5. Kitchen

   📏 Size: 9′-3″ × 7′-6″
   ➤ Functional kitchen with ample counter space and natural ventilation. Positioned beside the toilet and duct for plumbing ease.

6. Main Toilet (Attached)

   📏 Size: 5′-9″ × 3′-6″
   ➤ Common washroom near the bedroom and kitchen. Serves both family and guest needs.

7. Second Toilet (Optional/Attached)

   📏 Size: 3′-0″ × 3′-0″
   ➤ A small secondary toilet beside the OTS – useful for quick utility or washing needs.

8. O.T.S (Open to Sky / Shaft)

   📏 Size: Approx. 3′ x 3′
   ➤ Open duct space to enhance ventilation and natural lighting to the toilets and kitchen. Can be covered or landscaped creatively.

✅ Highlights:

• Spacious living + separate drawing room — ideal for family + guests

• Efficient layout for small plots

• Dual toilet setup with O.T.S. ventilation

• Best suited for urban infill plots or narrow plots

• Can be customized into 2BHK if needed by adjusting drawing/living space
